HPE Switch 1950-48G-2SFP+-2XGT com 48x 10/100/1000Mbps RJ45 + 2x portas 10G SFP+ e 2x portas 10G RJ45, Gerenciável empilhável JG961A

.Porta RJ45
– 48 portas 10/100/1000 Mbps RJ45
– Auto MDI/MDIX em todas as portas
– Full/half-duplex para velocidade Ethernet/Fast Ethernet
– 1 porta RJ45 Console

.Porta SFP 1G
– 2 portas SFP+ 1G/10G 1000/10000 (requer cartão SFP)
– 2 portas RJ45 1G/10G 10Gbase-T

>>> Suporta no total: 48 portas 10/100/1000 Mbps + 2 portas SFP+ 1G/10G + 2 portas 1/10GBaseT RJ45

>Padroes Suportados
– IEEE 802.3 Type 10BASE-T
– IEEE 802.3u Type 100BASE-TX
– IEEE 802.3ab Type 1000BASE-T
– IEEE 802.3z 1000BASE-X
– IEEE 802.3i 10BASE-T

>Protocolos suportados
– RFC 2819 RMON
– IEEE 802.1D MAC Bridges
– IEEE 802.1D Spanning Tree Protocol
– IEEE 802.1p Priority
– IEEE 802.1Q VLANs
– IEEE 802.1s Multiple Spanning Trees
– IEEE 802.1W Rapid Spanning Tree Protocol
– IEEE 802.1X
– IEEE 802.3ad Link Aggregation Control Protocol (LACP)
– IEEE 802.3x Flow Control
– IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
– IEEE 802.1D (STP)
– RFC 1215 SNMP Generic traps
– IEEE 802.1p (CoS)
– IEEE 802.1X Port Based Network Access Control

>Performace
– Memoria: 128 MB flash; 1 GB SDRAM
– Packet buffer size: 3.0 MB
– 100 Mb Latency: < 5.0 µs
– 1000 Mb Latency: < 5.0 µs
– 10 Gbps Latency: < 1.5 µs
– Throughput: até 130.9 Mpps (64-byte packets)
– Switching capacity: 176 Gbps
– Routing table size 32 entries (IPv4), 32 entries (IPv6)
– Tamanho tabela MAC address: 16,384 entradas

>Gerenciamento
– IMC – Intelligent Management Center
– Limited command-line interface
– Web browser
– SNMP Manager
– HTTPS
– RMON1
– FTP

>Alimentação
– Fonte 100 – 240 VAC, 50/60 Hz
– Consumo: Maximo: 54 watts

>Gabinete
– Formato: Altura 1U – montável em rack 19″
– Dimensoes: (44 x 27 x 4.4 cm
– Peso: 5.0kg

.Cartão SFP 1Gbps
– PN JD089B Cartao SFP 1G X120 RJ45
– PN JD118B Cartao SFP 1G X120 LC SX multimodo
– PN JD119B Cartao SFP 1G X120 LC LX monomodo
– PN J8177C Cartao SFP 1G X121 RJ45
– PN J4858C Cartao SFP 1G X121 LC SX multimodo
– PN J4859C Cartao SFP 1G X121 LC LX monomodo

.Cartão SFP 10Gbps
– PN JD092B Cartao SFP+ 10G X130 LC SR multimodo
– PN JD094B Cartao SFP+ 10G X130 LC LR monomodo
– PN J9150A Cartao SFP+ 10G X132 LC SR multimodo
– PN J9151A Cartao SFP+ 10G X132 LC LR monomodo

.Cabos
– PN JD095C HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable
Cabo DAC/Twinax para conexão em 10 GbE (conectores SFP+ em ambas as pontas)
– PN JD096C HPE X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable
Cabo DAC/Twinax para conexão em 10 GbE (conectores SFP+ em ambas as pontas)
– PN JD097C HPE X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
Cabo DAC/Twinax para conexão em 10 GbE (conectores SFP+ em ambas as pontas)
