HPE Switch 1920-8G com 8x 10/100/1000Mbps RJ45 + 2x portas 1G SFP JG920A

.Porta RJ45
– 8 portas 10/100/1000 Mbps RJ45
– Auto MDI/MDIX em todas as portas
– Full/half-duplex para velocidade Ethernet/Fast Ethernet
– 1 porta RJ45 Console

.Porta Gigabit
– 2 portas SFP 1G 1000Mbps(requer cartão SFP 1G)

>>> Suporta no total: 8 portas 10/100 Mbps + 2 portas SFP 1G

>Padroes Suportados
– IEEE 802.3 Type 10BASE-T
– IEEE 802.3u Type 100BASE-TX
– IEEE 802.3ab Type 1000BASE-T
– IEEE 802.3z 1000BASE-X

>Protocolos suportados
– IEEE 802.1D MAC Bridges
– IEEE 802.1p Priority
– IEEE 802.1Q VLANs
– IEEE 802.3x Flow Control
– IEEE 802.1s (MSTP)
– IEEE 802.1w Rapid Reconfiguration of Spanning Tree
– IEEE 802.3ad Link Aggregation Control Protocol (LACP)
– IEEE 802.1P (CoS)
– IEEE 802.1X Port Based Network Access Control
– IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
– IEEE 802.1D (STP)

>Performace
– Processador: MIPS @ 500 MHz
– Memoria: 32 MB flash, 128 MB RAM
– packet buffer size: 4.1Mb
– 100 Mb Latency: < 5 µs
– 1000 Mb Latency: < 5 µs
– Throughput: até 14.8 Mpps (64-byte packets)
– Switching capacity: 20 Gbps
– Tamanho tabela Roteamento: 32 entries (IPv4), 32 entries (IPv6)
– Tamanho tabela MAC address: 8,192 entradas

>Gerenciamento
– IMC – Intelligent Management Center
– limited command-line interface
– Web browser
– SNMP Manager
– IEEE 802.3 Ethernet MIB

>Alimentação
– Fonte 100 – 240 VAC, 50/60
– Consumo: Maximo: 9 watts
